EQ5250JSQFV - Suizhou Liyuan Trading Co., Ltd
  • Phone:Mr zhou +86 15997916929
  • Add time:2011-07-08 11:15:17
  • Hits:279
for the convenience of users to mention cars, our company agents to carry out car door-to-door delivery service.
the above price of vehicles, models, such as configuration and the color difference, please in order to prevail.
.
EQ5250JSQFV Detail - Suizhou Liyuan Trading Co., Ltd
Detailed parameters
EQ5250JSQFV  Model technical parameters
Name: EQ5250JSQFV Exterior size(mm): 10600,10800,11000,11200,11600,11800,12000X2480,2500,2550X3850,3980
Chassis: EQ5250JSQFVJ Container size(mm): 7100,7500,8200,8500X2300,2400X550,800
Total weight :(kg) 24900 Approach angle/ Departure angle(° ) 23/14,23/10,23/9,20/14,20/10,20/9
Payload:(kg) 9205,8905 Front suspension/rear suspension(mm): 1250/3050,1250/3450,1250/3500,1250/3400,1450/3050,1450/3450,1450/3500,1450/3200
Kerb Mass:(kg) 15500,15800(Kg) Max Speed(km/h): 90
Chassis parameters
Chassis: EQ5250JSQFVJ Axle weight: 6700/6700/11500
Number of axles: 3 Fuel Type: Diesel fuel
Wheelbase(mm): 2100+4200,2100+4750,2100+5250 Fronttread(mm):
Max people in cab: 3 Rear tread(mm):
Number of tires: Number of spring axle:
Tire Type:
introduction: 1、随底盘选装驾驶室,选装货厢样式及厢板结构、吊机操纵台位置及液压油箱位置。2、整车外形长度尺寸、轴距、接近角/离去角、前悬/后悬对应关系为:10600(10800),2100+4200,23(20)/14,1250(1450)/3050;11000(11200),2100+4200,23(20)/10,1250(1450)/3450;11600(11800),2100+4750,23(20)/9,1250(1450)/3500;12000,2100+5250,23(20)/9,1250(1450)/3400(3200)。3、可选装直臂式或折臂式吊机,型号/吊机重量(kg)/最大起升载荷(kg)/整备质量(kg)/载质量(kg)分别为:(SQS250,QYS-10,ZLC2500T,URV1004,KS2304,DFSQ25000,SQ1004):4200/10000/15500/9205;(SQS300,QYS-12,ZLC3000T,URV1204,KS2504,DFSQ30000,SQ1204):4500/12000/15800/8905;(SQZ200,QYS-10Z,HB170):4000/10000/15500/9205;(SQZ300,QYS-12Z,HB200):4300/12000/15800/8905。4、护栏材质:Q235,护栏与车架螺栓连接。后部防护断面尺寸(高×宽)为110×55 (mm),离地高度510mm。5、该车安装具有卫星定位功能的行驶记录仪。6、ABS的型号及生产厂家:J ABS/焦作博瑞克控制技术有限公司。
Engine parameters
Type Manufacturer Displacement(ml) Power(kw)
YC6JA220-50
ISB210
50
广西玉柴机器股份有限公司
东风康明斯发动机有限公司
6870
5900
162
155
other parameters
Introduction:
more Picture:
※ Need more information or pictures?please contact us and we will provide best service!。
